Composite Hose - We are leading manufacture of Flexible Composite Hoses With Assemblies

LOGANFLEX composite hoses have wide applications in many industries, and they can be divided into many kinds according to the application, such as chemical composite hose, petroleum composite hose, high temperature composite hose, cryogenic composite hose, biofuel and biodiesel composite hose, vapor recovery composite hose, bottom loading composite hose and fire retardant composite hose.

QUALITY ASSURANCE: We are providing Quality Assurance Internal & External Inspection certificates from reputed organizations such as Lloyds, DNV, and TUV.

QUALITY STANDARD: LOGANFLEX Composite hoses are manufactured & tested against industry standards including European Standards EN 13765:2018 and EN 13766 and British Standard BS 5842:1980.

PETROLEUM COMPOSITE HOSES
Petroleum composite hose is specially designed for tankers of highway and railway. It is soft and lightweight, and it is suitable for frequent bent mobile use. It has excellent anti-static performance. Tanker composite hose is suitable for all fuel oil products, such as gasoline, diesel, crude oil, lubricating oil, ethanol gasoline and biodiesel.
High temperature composite hose
This is a high tech fluropolymer very similar to the more commonly known PTFE (Poly Tetra Fluoro Ethylene) in its broad-spectrum chemical resistance but with the added advantage of high mechanical strength and low permeability. Typical applications are aggressive acids and those chemicals that attack polypropylene.
Biofuel and biodiesel composite hose
Composite hose is used for conveying biofuel and biodiesel. The hose can also give best solution to bioethanol in the applications of tank truck delivers and rail car loading. The structure of biofuel and biodiesel composite hose were inner helix wire (nylon coated steel, aluminum or SS316), outer helix wire (high tensile galvanized steel or stainless steel), liner (polyamide or nylon), carcass (multiple layers of polypropylene fabrics and films), and cover abrasion resistant PVC fabric.
Marine and Submersible Composite Hose
Marine and submersible composite hose is suitable for the suction and discharge of petroleum products for ship to ship and ship to shore. It can be used to transfer all types of oils, chemicals and aromatics in both positive and negative pressure This type is also designed for use with submersible pumps and for all other applications where the hose is exposed to the product like light chemicals and hydrocarbon, both on the inside and outside. It is recommended for applications as heavy duty marine operations and ship and barge loading and unloading.
CHEMICAL COMPOSITE HOSES
Chemical composite hoses is manufactured from multiple layers of polypropylene fabrics and films. The inner wire helix is available in 316 stainless steel and polypropylene coated steel. The outer wire helix is available in 316 stainless steel and Galvanised steel. It is also suitable for the delivery of chemical fluids which are corrosive and aggressive
standard heavy duty oil composite hoses
Standard and Heavy Duty composite hoses were applies, light hydrocarbons, Heavier hydrocarbons, Biofuel, Aromatics, Solvents transfer hoses, The inner & outer helix is available in galvanised steel and aluminium (inner). Standard duty version is used in rail car unloading and in plant transfers. Heavy duty is available for ship to shore and marine applications.
Cryogenic composite hose
Cryogenic composite hoses give the best conveying way of low temperature fluids due to our unremitting effort on the research and development. It is excellent in tensile load capacity, pressure capability and flexibility, unique hose construction, suitable for conveying marine low temperature LNG as well as other gases. Inner and outer wire are made of 316 stainless steel. Liner is constructed of combination of polyester and polyamide.
Fire Retardant Composite Hose
Fire retardant composite hose is specially designed for catastrophic situations and crisis conditions with thermal Insulation. Additional fire resistant films and fabrics are included in the hose construction. Its cover is made from special fiberglass which is coated with fire retardant PVC, making the hose have good thermal insulation and low conductivity from the outside to the inside. It is soft, making it bend freely. Besides, it is lightweight, making it easier to operate.
